CCG POSI FLEX Compression Cable Gland for Flexible Cable For use in highly corrosive or wet locations

Navigate to: CCG Home | CCG Industrial/Mining Cable Glands
CCG Unarmoured Cable Glands
CCG-POSI-FLEX-Compression-Cable-Gland-Flexible-Cable

CCG POSI FLEX Compression Cable Gland for Flexible Cable - For use in highly corrosive or wet locations.

Features and Benefits

For use in highly corrosive locations.
All brass parts encapsulated in a non-corrosive body.
Wide Sealing Range.
Complete with a fitted elastomeric seal to seal cable IP68.
Supplied with a brass locknut and polypropylene gasket.




CCG reserves the right to make alterations to the technical data, dimensions, designs and products available without notice. The illustrations cannot be considered binding. Please contact CGG for assistance.

Technical Data
Type - POSI FLEX
Gland Material - Brass Encapsulated in Glass Reinforced Polyester / PBT
Seal Material - Thermoplastic Elastomer
Cable Type - Unarmoured
Seal Material - Outer sheath
Optional Accessories - Locknut

Download Data Sheet
